Cadre |
Aluminium : 2022 Clash, 170 mm travel, 27.5 », Alloy 6066, triple butted tubes, T4, T6. Enduro bearings |
Fourche |
Fox 38 Performance, 180 mm, 27.5″, Fit Grip damper, 3 positions, rebound, Boost (15 x 110 mm), 37 mm offset, 1 Token |
Amortisseur |
Fox Float X2 Performance, 230 x 65 mm, rebound, compression, 2 positions adjustment |
Manette de dérailleur |
Shimano SLX, 1×12 vitesses |
Dérailleur arrière |
Shimano SLX, 12 vitesses |
Cassette |
Shimano SLX, 10-51 dents |
Pédalier |
Shimano SLX, 170 mm crank arms, Boost / Chainring : Shimano SLX, 32t, Dynamic Chain Engagement + Technology |
Boîtier de pédalier |
Shimano BB71-41A, Pressfit |
Freins |
Shimano SLX, 4 pistons, I-Spec EV compatible / Rotor : Shimano SM-RT76 203/203 mm, 6 holes |
Roues |
DT Swiss E532, 27.5 », 32h, 30 mm inner width |
Pneus |
Avant : Maxxis Assegai 27.5″ x 2.4″, WT, 3C MaxxTerra, EXO+, Tubeless Ready / Arrière : Maxxis DHR II 27.5″ x 2.5″, WT, 3C MaxxGrip, EXO+, Tubeless Ready |
Guidon |
Ride Alpha R20 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S – 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L – 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL |
Grips |
ODI Elite Motion, Soft pro compound, single clamp, black |
Potence |
Ride Alpha Freeride 40 mm extension, 31,8 mm |
Jeu de direction |
Acros ZS44/ZS56, Alloy cups, sealed bearings |
Selle |
Fizik Terra Alpaca X5, 145 mm width, S-alloy rails |
Tige de selle |
KS Rage-I, 34.9 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote |
Poids |
16.10 kg (Taille S) |
Coloris |
Dark Slate |
